Product Description
Fits:
- 1963 - 1964 Chevy C10
- 1963 - 1964 Chevy C10 Panel
- 1963 - 1964 Chevy Suburban
- 1963 - 1964 GMC 1000 Series Pickup
- 1963 - 1964 GMC Suburban
Includes:
- 1 - Set of Front Bag Mounts and Brackets
- 1 - Set of Rear Bag Mounts and Brackets
- 4 - Air Lift D2600 Dominator Air Bag Springs
- 1 - McGaughys Panhard Bar Adjustable
- 50 - Feet 1/4" Air Line
- 2 - Viair Schrader Valves
- 2 - 1/4" Tees
- 4 - 1/2" NPT to 1/4" PTC Bag Fittings
- Hardware
Mounts & Bracket Specs:
- Material: .188 CRS (Cold Rolled Steel)
- Cutting: CNC Laser
- Finish: Raw
- Manufactured in the USA by Grunion Fabrication
- Mounting Hardware: Included
Bag Specs:
- Air Lift Dominator D2600
- Stroke: 9.7"
- Single 1/2" Port
- Max Length: 12.5"
- Collapsed Length: 2.8"
- Max PSI: 600
- Max Diameter: 8"
- Collapse Force: 80 lbs
WARRANTY NOTICE: There are no Warranties, either expressed or implied. Neither the Seller nor Manufacturer will be liable for any loss, damage or injury, direct or indirect, arising from the use or inability to determine the appropriate use of any products. Before any attempt at installation, consult w/ a professional installer. In this connection, the user assumes all responsibility and risks. No Guarantees are made in reference to any specific class legality of any component. ALL PRODUCTS ARE INTENDED FOR TRACK OR OFF-ROAD USE AND MAY NOT BE LEGAL TO USE ON THE HIGHWAY. The products offered for sale are true track and off-road components and, in all cases, require Installation and or Fabrication SKILL. No product or service is designed or intended to PREVENT injury or DEATH.
Images are for illustrative purposes only, parts come in raw metal
