Product Description
Fits: Chevrolet Silverado 1500, 4WD, Trail Boss, AT4 and Diesel Models
WILL NOT FIT TRUCKS EQUIPPED W/ SINGLE MONO LEAF REAR SUSPENSION
Years: 2019,2020,2021,2022,2023
- 2 Spindles
- 1 Front Crossmember
- 1 Rear Crossmember
- 2 Compression Struts
- 2 Compression Strut Brackets
- 2 Lift Blocks
- 4 U-bolts & Hardware
- 2 Shock Extenders
- 2 Adjustable Front Struts
- 2 Rear Shocks
- 2 Tie Rod Ends
- 1 All Necessary Brake Line Brackets
- 1 Passenger Side Differential Side Brace
- 1 Front Drive Line Spacer w/ Bolts
- 1 Front Dive Line Boot Adapter w/ Clamp
- 2 Sway Bar Drop Brackets
- 1 Skid Plate
- 8 Stack-able Leaf Spring Shims
- 2 Leaf Spring Center Bolts
- 2 Rear Bump Stops
Notes:
Spindles and u-bolts are shipped with protective coating on surface. This allows them to be delivered to you without rust. We recommend you clean and paint the parts before you install, to protect against any future rust. Remember, spindles and u-bolts are bare metal. And will rust without paint.
If you are installing the provided rear lift shims, you will need rear drive-line spacer #50009
If running this kit at the 9″ position, we highly recommend using Upper Control Arms #50795 (sold separately) to help with bump stop clearance issues
Over-sized tires and heavier wheels can cause premature wear on factory and aftermarket components like ball joints, bushings, tie-rod ends, wheel bearings, idlers arms, drive-lines, etc… You may need to replace / install new components sooner than factory recommendations based on the wheels and tires you choose. Please note that the heavier and wider wheels and tires combined with aggressive driving (off-road and on highways) will cause more wear on ALL moving parts, factory and aftermarket. Especially when vehicle is in 4wd or Auto-4wd / AWD modes.
- Traction Bars #50719
- Upper Control Arms #50795
- Rear Drive Line Spacer #50009
