Product Description
Includes:
- 380C Pewter Air Compressor
- 2 Gallon Air Tank
- Pressure Switch (165 PSI On / 200 PSI Off)
- Safety Valve (250 PSI)
- Drain Cock
- Leader Hose with Check Valve
- 2 Gallon Air Tank
- Pressure Switch (165 PSI On / 200 PSI Off)
- Safety Valve (250 PSI)
- Drain Cock
- Leader Hose with Check Valve
Specifications:
12-Volt
Permanent Magnetic Motor
Duty Cycle: 100% @ 100 PSI (55% @ 200 PSI)
Max. Working Pressure: 200 PSI
12-Volt
Permanent Magnetic Motor
Duty Cycle: 100% @ 100 PSI (55% @ 200 PSI)
Max. Working Pressure: 200 PSI
Ingress Protection Rating: IP67
Max. Amp Draw: 23 Amps
Net Weight: 21.05 lbs.
Air Tank Temperature Rating: -40°C ~ +80°C
Air Tank Temperature Rating: -40°F ~ +176°F
Max. Amp Draw: 23 Amps
Net Weight: 21.05 lbs.
Air Tank Temperature Rating: -40°C ~ +80°C
Air Tank Temperature Rating: -40°F ~ +176°F
Fast-Fill 200 PSI Air Source Kits come with a powerful, low amp-draw 380C VIAIR compressor mounted on a 200 PSI-rated 2.0 gallon air tank with 5 ports. All 200 PSI Air Source kits come with a prewired 165/200 PSI pressure switch. Both kits not only come with the industry’s leading 200 PSI compressors but also come with a drain cock, safety valve, 3/8-inch port compression fitting for 1/2-inch air line preinstalled. To use, simply connect the pressure switch to fused power, make a solid ground and connect an air line to the compression fitting. A 40-amp relay and an appropriately-rated fuse is recommended for use with this unit.
|
Fill Rates
|
|
| 2.0 Gallon Tank | Fill Rate |
| 0 To 200 PSI | 5 Min 39 Sec. |
| 165 To 200 PSI | 1 Min 29 Sec. |
