Product Description
88P is a newly-designed, portable compressor, capable of inflating up to 33-inch tires. Attach the heavy duty battery clamps to your vehicle’s battery, and start the engine. Connect to a tire valve stem and turn the unit on. Tire pressure can easily be checked using the gauge incorporated into the top of the unit.
Features
- 120 PSI Pressure Gauge
- Solid Brass Twist-on Tire Chuck
- Battery Clamps
- Inflation Tips Kit
- LED Power Indicator / Work Light
- Power Cord: 9 ft. / Air Hose: 12 ft.
- 120 PSI Pressure Gauge
- Solid Brass Twist-on Tire Chuck
- Battery Clamps
- Inflation Tips Kit
- LED Power Indicator / Work Light
- Power Cord: 9 ft. / Air Hose: 12 ft.
Specifications
12-Volt
Permanent Magnetic Motor
Duty Cycle: 45% @ 100 PSI
Max. Working Pressure: 120 PSI
Max. Amp Draw: 19 Amps
Net Weight: 4.75 lbs.
12-Volt
Permanent Magnetic Motor
Duty Cycle: 45% @ 100 PSI
Max. Working Pressure: 120 PSI
Max. Amp Draw: 19 Amps
Net Weight: 4.75 lbs.
|
Fill Rates
|
|
| 225/60R18 | Fill Rate |
| 0 To 30 PSI | 2 Min. 30 Sec. (+/- 10 sec.) |
| 15 To 30 PSI | 1 Min. 19 Sec. (+/- 05 sec.) |
| 31" x 10.5" | Fill Rate |
| 0 To 30 PSI | 3 Min. 50 Sec. (+/- 10 sec.) |
| 15 To 30 PSI | 2 Min. 05 Sec. (+/- 05 sec.) |
| 33" x 12.5" | Fill Rate |
| 0 To 30 PSI | 5 Min. 45 Sec. (+/- 15 sec.) |
| 15 To 30 PSI | 2 Min. 56 Sec. (+/- 05 sec.) |
